Ultra QuickShot
Ultra QuickShot Airless Sprayer
Part Number: 20B473
Ultra QuickShot
Ultra QuickShot Airless Sprayer
Part Number: 20B473
The Ultra QuickShot is breakthrough technology, designed to deliver higher quality and provide results faster. Created for the perfect airless finish, while virtually eliminating spits. Built with extreme spray control to quickly adjust pressure for every application.
Questions About this Product?
If you’re not finding the information you need, ask one of our experts.
Ask an ExpertFeatures
Product Brochure
The Ultra QuickShot is breakthrough technology, designed to deliver higher quality and provide results faster. Created for the perfect airless finish, while virtually eliminating spits. Built with extreme spray control to quickly adjust pressure for every application.
The industry's most portable sprayer gives you the ability to spray in the tightest of areas with precision and the highest control. Spray the widest range of architectural coatings, from water based paints, to solvents, and flammable based materials. Perfect for small jobs such as cabinets, doors, trim, soffits, gutters and more.
- Instant Response Electric Powered Gun Virtually Eliminates Spits
- Reduce fatigue with industry's lightest trigger pull
- Smallest, lightest airless gun ever built
- Responds instantly to produce the best finish
- On-Demand Precision Flow-Control System
- Quickly adjust material flow for extreme airless spray control
- Easily dial-in to your desired pressure from 100-2,000 psi
- 6 ft Flexible Hose For Full Reach & Easy Hose Management
- Easily prime, change colors, and clean in seconds
- Gun and hose hold only 1 oz of coating
- QuickShot ProConnect Airless Piston Pump
- Durable long-life triple piston pump
- 32 oz Pour-N-Go Cup
- Easy fill design - refill on your hip
- Spray small amounts FAST
- Power to Take on Every Small Job
- Comes with two DEWALT 20V Lithium-ion batteries
- Spray up to one gallon on each battery
- Ultimate Hands-Free Portability With Belt and Holster Attachment
Specifications & Documents
Technical Specifications
Convert to Metric| Battery Voltage (V) | 20 |
|---|---|
| Maximum Operating Temperature (°F) | 90 |
| Maximum Storage Temperature (°F) | 113 |
| Maximum Tip Size (in) | 0.016 |
| Maximum Working Pressure (MPa) | 14 |
| Maximum Working Pressure (psi) | 2000 |
| Minimum Operating Temperature (°F) | 40 |
| Minimum Storage Temperature (°F) | 32 |
| Model | Ultra |
| Overall Height (in) | 10.5 |
| Overall Length (in) | 12 |
| Overall Width (in) | 6 |
| Power Source | Battery Powered |
| Series | QuickShot |
| Sound Pressure Level (dB(A)) | 83 |
| Type | Airless Spray Package |
| Weight (lb) | 6.4 |
| Battery Voltage (V) | 20 |
| Maximum Operating Temperature (°C) | 32 |
| Maximum Storage Temperature (°C) | 45 |
| Maximum Tip Size (in) | 0.016 |
| Maximum Working Pressure (MPa) | 14 |
| Maximum Working Pressure (bar) | 138 |
| Maximum Working Pressure (psi) | 2000 |
| Minimum Operating Temperature (°C) | 4 |
| Minimum Storage Temperature (°C) | 0 |
| Model | Ultra |
| Overall Height (cm) | 26.7 |
| Overall Length (cm) | 30.5 |
| Overall Width (cm) | 15.2 |
| Power Source | Battery Powered |
| Series | QuickShot |
| Sound Pressure Level (dB(A)) | 83 |
| Type | Airless Spray Package |
| Weight (kg) | 2.9 |
Product Manuals
Sales Literature
What's Included
| Part No. | Description | Qty | Unit |
|---|---|---|---|
| FFLP514 | Fine Finish Low Pressure RAC X FF LP SwitchTip, 514 | 1 | ea |
| 246215 | RAC X HandTite Tip Guard | 1 | ea |
| 17M883 | Storage Case | 1 | ea |
| FFLP210 | Fine Finish Low Pressure RAC X FF LP SwitchTip, 210 | 1 | ea |
| 17P474 | DEWALT 20V MAX 2.0 Ah Lithium Ion Battery Pack | 2 | ea |
| 17P475 | DEWALT 20V MAX Lithium Ion Battery Charger | 1 | ea |
| 18F891 | Replacement Belt | 1 | ea |
