QUANTM i120
QUANTM i120, 2"Flange, Polypropylene Electric Diaphragm Pump, 200-240 V, AL Center, PP Seat, SP Ball, SP Diaphragm
Part Number: TE120-0014
![product image](/content/dam/pim/graco/pro/pte/QUANTM_i120_PP_FF.jpg/_jcr_content/renditions/cq5dam.web.1280.1280.jpeg)
QUANTM i120
QUANTM i120, 2"Flange, Polypropylene Electric Diaphragm Pump, 200-240 V, AL Center, PP Seat, SP Ball, SP Diaphragm
Part Number: TE120-0014
QUANTM isn’t just another electric pump: it’s a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, ...
More Info
Questions About this Product?
If you’re not finding the information you need, ask one of our experts.
Ask an ExpertFeatures
Product Brochure
QUANTM isn’t just another electric pump: it’s a game-changer. QUANTM features a revolutionary electric motor design that will reduce operational costs and delivers the reliability to keep your production lines running. With multiple fluid path options containing different materials of construction, QUANTM is ideal for most fluid applications as a highly reliable drop-in replacement for your current less-efficient pneumatic pumps or a perfect fit for greenfield construction. The unique self-priming, seal-less design delivers smooth and steady flow and is the only electric diaphragm pump on the market that stalls under pressure to reduce downtime caused by pump failures from clogged lines or closed valves. QUANTM is engineered to be quieter, more efficient and ultra-dependable while delivering energy savings that will go a long way to reinforcing your sustainability reputation. It’s time to rethink your pump strategy and elevate your bottom line by converting to a QUANTM electric pump.
Designed with a chemical-resistant polypropylene fluid section that provides high corrosion resistance, this groundbreaking electric pump is built to efficiently handle fluid transfer applications involving most chemicals and detergents, sump evacuation applications, as well as applications involving high and low pH materials. With up to 8x more continuous torque at low speeds than conventional motors, this powerful new pump delivers a higher level of reliability to minimize downtime while the plug-and-play design makes it easy to drop into any production line without additional investment or infrastructure rework.
- Revolutionary Design
- Replace existing air operated pumps with electric pump technology that stalls under pressure and includes AutoPrime feature
- Compact and efficient electric drive removes the gearbox providing a comparable footprint to a pneumatic diaphragm pump
- Up to 80% reduction in energy consumption compared to pneumatic pumps, reducing operating costs and providing a quick investment payback
- Quiet operation reduces plant noise and improves employee safety and health
- Smart pump control provides more accurate flow set points and built-in I/O
- Efficient Electric Motor
- Powder-coated aluminum electric drive
- 240 VAC 3φ motor with 15 ft cord and NEMA L15-20 plug
- Non-hazardous
- Materials of Construction
- Polypropylene fluid section with end flange
- Internal components include polypropylene seat, Santoprene ball, Santoprene diaphragm and PTFE manifold o-ring
Specifications & Documents
Technical Specifications
Convert to MetricApplication | Chemical Processing, Paints and Coatings, Waste Water, General Fluid Transfer |
---|---|
Ball Material | Santoprene |
Center Section Material | Aluminum |
Connection Type | Flange |
Construction | Polypropylene, Santoprene, PTFE |
Cord Length (ft) | 15 |
Diaphragm Material | Santoprene |
Fluid Inlet Size (in) | 2 |
Fluid Inlet Thread Gender | Flange |
Fluid Inlet Thread Type | Flange |
Fluid Outlet Size (in) | 2 |
Fluid Outlet Thread Gender | Flange |
Fluid Outlet Thread Type | Flange |
Fluid Passage Size (in) | 2 |
Fluid Passage Size (mm) | 51 |
Fluid Section | Polypropylene, End Flange |
Fluid Section Material | Polypropylene |
Hazardous Location Approval | None |
Manifold Configuration | End Flange |
Manifold O-Ring Material | PTFE |
Maximum Ambient Temperature (°F) | 104 |
Maximum Amperage (A) | 7.5 |
Maximum Flow Rate (GPM) | 120 |
Maximum Fluid Operating Temperature (°C) | 66 |
Maximum Fluid Operating Temperature (°F) | 150 |
Maximum Fluid Pressure (psi) | 60 |
Maximum Solid Size (in) | 0.25 |
Minimum Fluid Operating Temperature (°C) | 0 |
Minimum Fluid Operating Temperature (°F) | 32 |
Model | QUANTM |
Motor Type | Electric Drive |
Overall Height (in) | 25.7 |
Seat Material | Polypropylene |
Series | i120 |
Type | Electric Diaphragm Pump |
Voltage (V ac) | 240 VAC 3Ph |
Weight (lb) | 100 |
Application | Chemical Processing, Paints and Coatings, Waste Water, General Fluid Transfer |
Ball Material | Santoprene |
Center Section Material | Aluminum |
Connection Type | Flange |
Construction | Polypropylene, Santoprene, PTFE |
Cord Length (m) | 4.57 |
Diaphragm Material | Santoprene |
Fluid Inlet Size (in) | 2 |
Fluid Inlet Size (mm) | 51 |
Fluid Inlet Thread Gender | Flange |
Fluid Inlet Thread Type | Flange |
Fluid Outlet Size (in) | 2 |
Fluid Outlet Size (mm) | 50.8 |
Fluid Outlet Thread Gender | Flange |
Fluid Outlet Thread Type | Flange |
Fluid Passage Size (in) | 2 |
Fluid Passage Size (mm) | 51 |
Fluid Section | Polypropylene, End Flange |
Fluid Section Material | Polypropylene |
Hazardous Location Approval | None |
Manifold Configuration | End Flange |
Manifold O-Ring Material | PTFE |
Maximum Ambient Temperature (°C) | 40 |
Maximum Amperage (A) | 7.5 |
Maximum Flow Rate (L/min) | 454 |
Maximum Fluid Operating Temperature (°C) | 66 |
Maximum Fluid Operating Temperature (°F) | 150 |
Maximum Fluid Pressure (bar) | 4.14 |
Maximum Fluid Pressure (kPa) | 414 |
Maximum Fluid Pressure (psi) | 60 |
Maximum Solid Size (mm) | 6.4 |
Minimum Fluid Operating Temperature (°C) | 0 |
Minimum Fluid Operating Temperature (°F) | 32 |
Model | QUANTM |
Motor Type | Electric Drive |
Seat Material | Polypropylene |
Series | i120 |
Type | Electric Diaphragm Pump |
Voltage (V ac) | 240 VAC 3Ph |
Product Manuals
Sales Literature
Certifications
MSD201EN, Loctite 567 Low Strength Thread Sealant, Safety Data Sheet, English
(141 KB)
(English Only)
Repair Parts
Part No. | Description |
---|---|
2000217 | QUANTM i120 Complete Fluid Repair Kit with PP Seat, SP Ball, SP Diaphragm and PT Seal |
D0F060 | 2-inch Santoprene Check Ball Kit |
D0F900 | 2-inch Polypropylene Seat Kit |
D0GA00 | 2-inch PVDF Seat Kit |
25V209 | QUANTM i/h120 Santoprene Diaphragm Kit |
26B352 | 2-inch PTFE Seal Kit |
25F124 | QUANTM i/h120 Rotor Kit |
25F102 | QUANTM i-Series Pump Control Knob for Ordinary Location Industrial Pump Models |
25V133 | QUANTM i120 Stator Cap Kit |
19B738 | Power Cord for Ordinary Location F-1 Motor QUANTM Pumps |
