Ultra 490 XT

Ultra 490 XT Electric Airless Sprayer, Stand

Part Number: 19D519

product image product image product image product image product image product image
New

Ultra 490 XT

Ultra 490 XT Electric Airless Sprayer, Stand

Part Number: 19D519

The Ultra 490 XT delivers an airless spray experience like no other. Featuring a 1.3 HP Xtreme Torque motor, Next Generation Rapid-Response Pressure Control, elevated performance, and the longest life pump in its class, the Ultra 490 XT is sure to become a staple in your fleet.
Questions About this Product?

If you’re not finding the information you need, ask one of our experts.

Ask an Expert

Features

Product Brochure
The Ultra 490 XT delivers an airless spray experience like no other. Featuring a 1.3 HP Xtreme Torque motor, Next Generation Rapid-Response Pressure Control, elevated performance, and the longest life pump in its class, the Ultra 490 XT is sure to become a staple in your fleet.

Xtreme Productivity. Xtreme Reliability. Graco's Xtreme Torque Midsize Electric sprayers make it easier to get more work done in a day with increased flow and production rates.

  • Xtreme Torque Motor Technology
    • 15X more torque than traditional motors
    • 8X more magnets provide unmatched power and performance
    • 90% lower running speeds extend motors life
    • Up to 10X quieter
  • Rapid-Response Pressure Control
    • Instantly responds to deliver the best finish quality
    • More performance across its full tip size range
    • Industry's largest operating pressure range (50-3,300 psi)
  • Selectable Performance Modes
    • Two selectable spray modes offer unique performance levels to boost efficiency on every job
    • Bring on the savings and achieve Xtreme Control with Low Pressure Mode (50 - 2,000 psi)
    • Use High Pressure Mode for Xtreme Performance (500 – 3,300 psi)
  • Easy-to-Read LED Digital Display
    • Visible in even the toughest spraying conditions
  • Endurance Vortex Piston Pump with ProConnect
    • Endurance Vortex Rod lasts 3X longer than the closest competitor
    • ProConnect Pump Removal for fast on-the-job service
  • TurboClean Cleaning System
    • Industry’s fastest pump cleaning system
    • Delivers 3X faster cleaning with 1/2 the water
    • Convenient location
  • WatchDog Pump Protection
    • Prevents damage by shutting off pump when it's time to refill
  • Durable Filtration
    • Easy Out Filter provides easy maintenance and less clogging
  • Easy Transport
    • Only 31 lbs (Stand)
  • Gun, Hose and Tip Included
    • Contractor PC Gun & RAC X LP 517 SwitchTip

Specifications & Documents

Technical Specifications

Convert to Metric
Frame Configuration Stand
Maximum Flow Rate (GPM) 0.7
Maximum Tip Size (in) .025
Maximum Working Pressure (psi) 3300
Minimum Working Pressure (psi) 50
Model Ultra
Series 490 XT
Type Airless Sprayer
Voltage (V) 120
Weight (lb) 36
Frame Configuration Stand
Maximum Tip Size (in) .025
Maximum Working Pressure (psi) 3300
Minimum Working Pressure (psi) 50
Model Ultra
Series 490 XT
Type Airless Sprayer
Voltage (V) 120

Repair Parts

Part No. Description
18B260 Graco Pump Repair Kit
