LineLazer 3400
LineLazer 3400 Gas Airless Line Striper, 1 Manual Gun
Part Number: 25M224
LineLazer 3400
LineLazer 3400 Gas Airless Line Striper, 1 Manual Gun
Part Number: 25M224
The LineLazer 3400 is the professional choice for dependable, 1-gun striping for small parking lots, mini malls, seal coating contractors, schools and park and recreation departments.
Questions About this Product?
If you’re not finding the information you need, ask one of our experts.
Ask an ExpertFeatures
Product Brochure
The LineLazer 3400 is the professional choice for dependable, 1-gun striping for small parking lots, mini malls, seal coating contractors, schools and park and recreation departments.
- Updated Frame
- Improved Tracking & Line Quality
- Added stability with newly designed, 3-inch longer frame
- Accepts 15-gallon hopper and EZ Bead System
- Rear Mount Hose Wrap
- Easier Stencil Jobs
- Easy on/off functionality
- Easy-To-Reach Controls
- Fine-tune the striper without stopping
- Operator controls are located on the handlebars
- New Handlebar Design
- Reduced Vibration
- Less operator fatigue with greater comfort and control
- Electronic Pressure Control
- Improved Line Quality
- Accurate, tight tolerance system
- Endurance Chromex Pump
- Reliable, Long-Life Pump
- Industry-best pump performance — field-proven design
- Handle the most demanding materials with long-life rod treatment
- 4X harder than ordinary chrome
- Honda GX Engine
- Reliable, Easy-to-Start Power
- Contractor-preferred — excellent power and proven reliability
- Oil Alert shuts down engine to prevent damage if oil level drops too low
- Easy Out Pump Filter
- Easy Pump Maintenance & Less Clogging
- Inside-out design means less mess with fewer tip clogs
- Front Swivel Wheel
- Easier Maneuverability
- Ability to stripe right up to the curb
- Makes easy work of hard-to-do curves
- Years of dependable operation with tapered locking pin design
Specifications & Documents
Technical Specifications
Convert to Metric| Attachments | None |
|---|---|
| Compatible Material | Road-Marking Paint |
| Compatible Surfaces | Pavement, Turf |
| Engine Brand | Honda |
| Engine Model | GX120 |
| Fuel Tank Capacity (gal) | 0.66 |
| Gun Activation | 1 Manual |
| Hopper Volume Capacity (gal) | 15 |
| Includes | Flex Plus Gun, LineLazer RAC 5 317 Spray Tip, LineLazer RAC 5 319 Spray Tip, RAC 5 Tip Guard, 1/4 in x 50 ft (15 m) BlueMax II Airless Hose, 1/4 in x 3 ft (0.9 m) BlueMax II Airless Whip Hose, TSL, 4 oz (118 ml) |
| Maximum Flow Rate (GPM) | 0.75 |
| Maximum Sound Pressure Level (dB(A)) | 91 |
| Maximum Tip Size (in) | 0.027 |
| Maximum Working Pressure (psi) | 3300 |
| Model | LineLazer |
| Number of Colors | One Color |
| Number of Guns | 1 |
| Number of Pumps | 1 |
| Overall Height (in) | 39.4 |
| Overall Length (in) | 66.3 |
| Overall Width (in) | 26.0 |
| Power Rating (HP) | 4 |
| Power Rating (W) | 2980 |
| Power Rating (kW) | 2.98 |
| Power Source | Gas |
| Product Series | Standard |
| Pump Type | Endurance |
| Recommended Annual Usage | Up to 250 gallons per week |
| Series | 3400 |
| Type | Walk-Behind Line Striper |
| Weight (lb) | 160 |
| Attachments | None |
| Compatible Material | Road-Marking Paint |
| Compatible Surfaces | Pavement, Turf |
| Engine Brand | Honda |
| Engine Model | GX120 |
| Fuel Tank Capacity (L) | 2.5 |
| Gun Activation | 1 Manual |
| Hopper Volume Capacity (L) | 56.8 |
| Includes | Flex Plus Gun, LineLazer RAC 5 317 Spray Tip, LineLazer RAC 5 319 Spray Tip, RAC 5 Tip Guard, 1/4 in x 50 ft (15 m) BlueMax II Airless Hose, 1/4 in x 3 ft (0.9 m) BlueMax II Airless Whip Hose, TSL, 4 oz (118 ml) |
| Maximum Flow Rate (L/min) | 2.8 |
| Maximum Sound Pressure Level (dB(A)) | 91 |
| Maximum Tip Size (cm) | 0.0686 |
| Maximum Tip Size (in) | 0.027 |
| Maximum Tip Size (mm) | 0.6858 |
| Maximum Working Pressure (bar) | 227 |
| Maximum Working Pressure (kPa) | 2270 |
| Maximum Working Pressure (psi) | 3300 |
| Model | LineLazer |
| Number of Colors | One Color |
| Number of Guns | 1 |
| Number of Pumps | 1 |
| Overall Height (cm) | 100.0 |
| Overall Height (mm) | 1000.76 |
| Overall Length (cm) | 168.4 |
| Overall Length (mm) | 1684.02 |
| Overall Width (cm) | 66.0 |
| Overall Width (mm) | 660.4 |
| Power Rating (W) | 2980 |
| Power Rating (kW) | 2.98 |
| Power Source | Gas |
| Product Series | Standard |
| Pump Type | Endurance |
| Recommended Annual Usage | Up to 250 gallons per week |
| Series | 3400 |
| Type | Walk-Behind Line Striper |
| Weight (kg) | 73 |
Product Manuals
Sales Literature
What's Included
| Part No. | Description | Qty | Unit |
|---|---|---|---|
| 248157 | Flex Plus Airless Spray Gun, 2 Finger Trigger, RAC 5 LineLazer | 1 | ea |
| LL5317 | LineLazer RAC 5 SwitchTip, 317 | 1 | ea |
| LL5319 | LineLazer RAC 5 SwitchTip, 319 | 1 | ea |
| 243161 | RAC 5 HandTite Tip Guard | 1 | ea |
| 240794 | BlueMax II Airless Hose, 1/4 in x 50 ft | 1 | ea |
| 238049 | TSL Throat Seal Liquid, 4 oz | 1 | ea |
Repair Parts
| Part No. | Description |
|---|---|
| 244067 | Easy Out Pump Manifold Filter, Long, 60 mesh |
| 249080 | Coupled Hose- 1/4 in. Diameter, 50 ft. Long |
| 246385 | Inlet Strainer, Nylon Cap, 7/8 in |
| 116752 | SWITCH, ROCKER |
| 239914 | Replacement Drain Valve Kit |
| 248157 | Flex Plus Airless Spray Gun, 2 Finger Trigger, RAC 5 LineLazer |
