Comparing 2k Meter, Mix & Dispense Systems
Broad Range of Applications
For precision sealant and adhesive metering, Graco's advanced two-component meter mix dispense (MMD) systems offer reliable accuracy for a broad range of applications such as bonding and sealing, potting, gasketing, encapsulation, form-in-place gasketing (FIPG), and thermal gap filling.
Our meter mix dispense machines can be configured to meet your specific production requirement. For a system recommendation suited to your application and material selection, contact our experts.
2k Comparison Chart
|
|
|
|
|
|
| ||||||||
| Minimum Shot Size | 0.005cc to 5cc | 0.01 cc to 100 cc | 2 cc to 70 cc | 0.3 cc | 30 cc | 0.3 cc | ||||||||
| Fixed Ratio |  |  | | | | | ||||||||
| Adjustable Ratio | * | ** | * | * | * | * | ||||||||
| Ratios | 1:1 to 25:1 | 1:1 to 10:1 | 1:1 to 24:1 | 1:1 to 12:1 | 1:1 to 32:1 | 1:1 to 50:1 | ||||||||
| Drive | Pneumatic or Servo | Servo | Pneumatic or Servo | Servo | Hydraulic | Servo | ||||||||
| Shot | Yes | | | | | | ||||||||
| Bead | Yes | | | | | | ||||||||
| Continuous Flow | | | | | | | ||||||||
| Low Viscosity or Pourable Materials | | | | | | | ||||||||
| Medium Viscosity | | | | | | | ||||||||
| High Viscosity or Non-Flow | | | | | | | ||||||||
| Supply Type | Supply Pumps | Cartridge or Supply Pumps | Day Tanks or Supply Systems | Supply Systems | Day Tanks and Supply Systems | Day Tanks and Supply Systems | ||||||||
| System features and performance can vary depending on the material and application. Contact our experts for a recommendation suited to your production process. *System ratios can be adjusted by replacing pump sizes. ** Adjustable via software | ||||||||||||||
