Manzel Model 25
Manzel® Model 25 Compressor Lubricator Replacement Pump, 5/16 in (7.9 mm), 1000 psi (69 bar)
Part Number: 562950
Image is for illustrative purposes only.
Manzel Model 25
Manzel® Model 25 Compressor Lubricator Replacement Pump, 5/16 in (7.9 mm), 1000 psi (69 bar)
Part Number: 562950
Provide lubrication to cylinder walls, bearings and other moving parts of equipment such as sugar mills, steam engines, presses and general machinery.
Questions About this Product?
If you’re not finding the information you need, ask one of our experts.
Ask an ExpertFeatures
Product Brochure
Provide lubrication to cylinder walls, bearings and other moving parts of equipment such as sugar mills, steam engines, presses and general machinery.
- General-purpose lubrication: automatic, precision metering for all types of machinery
- Clear-Vue pumping unit shows amount of lubricant being pumped
- Self-contained, removable pumping unit. All units interchangeable - remove two pump screws and lift out
- Convenient hand crank for rapid priming of lines before start-up or for momentarily increasing supply of lubricant
- Lubriquip part number 321-410-015
- Manzel part number 60050-B
Specifications & Documents
Technical Specifications
Convert to Metric| Compatible Material | Oil |
|---|---|
| Construction | Fluoroelastomer, Gray Iron, Carbon Steel, Alloy Steel, Stainless Steel |
| Drive Option | Direct Rotary |
| Lubricator Feed Type | Force Feed |
| Maximum Drive Speed (RPM) | 60 |
| Maximum Fluid Viscosity (SUS) | 5000 |
| Maximum Number of Drops Per Stroke (drops/stroke) | 12 |
| Maximum Working Pressure (psi) | 1000 |
| Minimum Drive Speed (RPM) | 3 |
| Minimum Fluid Viscosity (SUS) | 100 |
| Minimum Number of Drops Per Stroke (drops/stroke) | 0.25 |
| Model | Manzel |
| Outlet Size (in) | 1/4 |
| Outlet Thread Gender | Female |
| Outlet Thread Type | NPS |
| Overall Depth (in) | 25.59 |
| Overall Height (in) | 8.50 |
| Overall Width (in) | 6 |
| Piston Size (in) | 0.31 |
| Pump Size (in) | 5/16 |
| Reservoir Material | Steel |
| Series | Model 25 |
| Type | Box Lubricator |
| Compatible Material | Oil |
| Construction | Fluoroelastomer, Gray Iron, Carbon Steel, Alloy Steel, Stainless Steel |
| Drive Option | Direct Rotary |
| Lubricator Feed Type | Force Feed |
| Maximum Drive Speed (RPM) | 60 |
| Maximum Fluid Viscosity (SUS) | 5000 |
| Maximum Number of Drops Per Stroke (drops/stroke) | 12 |
| Maximum Working Pressure (bar) | 69 |
| Maximum Working Pressure (kPa) | 6900 |
| Maximum Working Pressure (psi) | 1000 |
| Minimum Drive Speed (RPM) | 3 |
| Minimum Fluid Viscosity (SUS) | 100 |
| Minimum Number of Drops Per Stroke (drops/stroke) | 0.25 |
| Model | Manzel |
| Outlet Size (cm) | 0.635 |
| Outlet Size (in) | 1/4 |
| Outlet Size (mm) | 6.35 |
| Outlet Thread Gender | Female |
| Outlet Thread Type | NPS |
| Overall Depth (cm) | 65 |
| Overall Depth (mm) | 650 |
| Overall Height (cm) | 21.6 |
| Overall Height (mm) | 215.9 |
| Overall Width (cm) | 15.24 |
| Overall Width (mm) | 152.4 |
| Piston Size (cm) | 0.79 |
| Piston Size (mm) | 7.9 |
| Pump Size (cm) | 0.8 |
| Pump Size (mm) | 8 |
| Reservoir Material | Steel |
| Series | Model 25 |
| Type | Box Lubricator |
