Pro-Shot
Pro-Shot™ Dispense Valve - 1/4 NPT Inlet With Coupler and Extension
Part Number: 242056
![product image](/content/dam/pim/graco/led/pmg/242056_Grease_Valve.jpg/_jcr_content/renditions/cq5dam.web.1280.1280.jpeg)
Image is for illustrative purposes only.
Pro-Shot
Pro-Shot™ Dispense Valve - 1/4 NPT Inlet With Coupler and Extension
Part Number: 242056
For heavy-duty applications, this non-metered dispense valve is designed to perform in heavy equipment shops, fleet maintenance shops, and municipal garages.
Questions About this Product?
If you're not finding the information you need, ask one of our experts.
Ask an ExpertFeatures
Product BrochureFor heavy-duty applications, this non-metered dispense valve is designed to perform in heavy equipment shops, fleet maintenance shops, and municipal garages.
Typical applications include service shops, Heavy-duty dealerships, Fast lube centers, Automotive dealerships, In-plant, Lube trucks, and Mining.
- Pressure-assisted trigger for ease of operation
- Easy top adjustment with locking nut
- Rugged design to withstand harsh environments
- Inlet 1/4 in. NPT
- Includes coupler and extension
Specifications & Documents
Technical Specifications
Convert to MetricCompatible Material | Grease |
---|---|
Construction | Chrome Vanadium, Polyurethane, Brass, Carbon Steel, Alloy Steel |
Extension Type | Rigid |
Includes | Coupler |
Inlet Size (in) | 1/4 |
Inlet Thread Gender | Female |
Inlet Thread Type | NPT |
Maximum Working Pressure (psi) | 8000 |
Model | Pro-Shot |
Outlet Thread Gender | Female |
Outlet Thread Type | NPT |
Power Type | Manual |
Trigger Lock | Non-Locking |
Type | Dispense Valve |
Valve Type | Non-Metered |
Compatible Material | Grease |
Construction | Chrome Vanadium, Polyurethane, Brass, Carbon Steel, Alloy Steel |
Extension Type | Rigid |
Includes | Coupler |
Inlet Size (cm) | 0.64 |
Inlet Size (in) | 1/4 |
Inlet Size (mm) | 6.35 |
Inlet Thread Gender | Female |
Inlet Thread Type | NPT |
Maximum Working Pressure (bar) | 552 |
Maximum Working Pressure (kPa) | 55200 |
Maximum Working Pressure (psi) | 8000 |
Model | Pro-Shot |
Outlet Thread Gender | Female |
Outlet Thread Type | NPT |
Power Type | Manual |
Trigger Lock | Non-Locking |
Type | Dispense Valve |
Valve Type | Non-Metered |
