G-Mini® Grease Lubrication Pump with Controller, 24 VDC, 1 Liter
Part Number: 25R801
Make the most of your space, budget and machines. The new full-featured G-Mini offers reliable lubrication in a small footprint to fit more types of machines. Use it to simplify everyday maintenance, extend lifecycles and optimize uptime. It’s rugged and tough, perfect for handling the daily, 24/7 r...
More Info
Questions About this Product?
If you’re not finding the information you need, ask one of our experts.
Ask an ExpertG-Mini Support
Educate yourself on the G-Mini lubrication pumps by visiting the support page. Easily access manuals, wiring diagrams and educational videos, all in one central location.
Features
Product Brochure
Make the most of your space, budget and machines. The new full-featured G-Mini offers reliable lubrication in a small footprint to fit more types of machines. Use it to simplify everyday maintenance, extend lifecycles and optimize uptime. It’s rugged and tough, perfect for handling the daily, 24/7 rigors of any job, both big and small. Best of all, it comes with a modest price tag – boosting your productivity and profitability.
- Follower Plate and Stir Paddle - This unique combination combats oil separation while ensuring the pump element “loading chamber” is always full.
- M12 Input - M12 cycle or proximity switch input standard on all pumps with a controller.
- 5-Wire CPC Power Cable - Multifunction cable supplies power to the pump, pairs with a remote manual run button, and provides low level or cycle fault output.
- 1 liter reservoir option
- One Pump Element - 0.18 in3/min (3 cm3/min), 4,100 psi (280 bar)
- Easy-to-program controller can be utilized for both time based and cycle based systems and provides low level alert and alarm.
- Rugged Construction - Designed to withstand the harshest of environments; IP69K rated.
Specifications & Documents
Technical Specifications
Convert to Metric| Application | Off-Road Equipment, On-Road Vehicles, Industrial, Wind Energy |
|---|---|
| Approvals | CE, EAC |
| Compatible Material | Grease |
| Compatible Metering Device | Series Progressive |
| Construction | Carbon Steel, Alloy Steel, Stainless Steel, Nitrile Rubber, Bronze, Nickel Plated Alnico, Chemically Lubricated Acetal, Aluminum, PTFE, Amorphous Polyamide, Nylon |
| Control Options | Internal Controller |
| Fluid Inlet Type | Zerk Fitting to Fill Reservoir |
| Fluid Outlet Size (in) | 1/4 |
| Fluid Outlet Thread Gender | Female |
| Fluid Outlet Thread Type | NPSF |
| IP Rating | IP69K |
| Maximum Flow Rate (ci/min) | 3 |
| Maximum NLGI Grade | #2 |
| Maximum Operating Temperature (°F) | 158 |
| Maximum Voltage (V dc) | 32 |
| Maximum Working Pressure (psi) | 4061 |
| Minimum Operating Temperature (°F) | 5 |
| Minimum Voltage (V dc) | 18 |
| Model | G-Mini |
| Number of Pump Elements | Up to 2 |
| Number of Sensor Inputs | 1 |
| Overall Depth (in) | 6.57 |
| Overall Height (in) | 12.2 |
| Overall Width (in) | 6.97 |
| Power Connection Type | CPC |
| Reservoir Size (L) | 1 |
| Type | Electric Piston Pump |
| Voltage (V dc) | 24 |
| Voltage (V) | 24 |
| Weight (lb) | 8.8 |
| Application | Off-Road Equipment, On-Road Vehicles, Industrial, Wind Energy |
| Approvals | CE, EAC |
| Compatible Material | Grease |
| Compatible Metering Device | Series Progressive |
| Construction | Carbon Steel, Alloy Steel, Stainless Steel, Nitrile Rubber, Bronze, Nickel Plated Alnico, Chemically Lubricated Acetal, Aluminum, PTFE, Amorphous Polyamide, Nylon |
| Control Options | Internal Controller |
| Fluid Inlet Type | Zerk Fitting to Fill Reservoir |
| Fluid Outlet Size (in) | 1/4 |
| Fluid Outlet Thread Gender | Female |
| Fluid Outlet Thread Type | NPSF |
| IP Rating | IP69K |
| Maximum NLGI Grade | #2 |
| Maximum Operating Temperature (°C) | 70 |
| Maximum Voltage (V dc) | 32 |
| Maximum Working Pressure (bar) | 280 |
| Maximum Working Pressure (psi) | 4061 |
| Minimum Operating Temperature (°C) | -15 |
| Minimum Voltage (V dc) | 18 |
| Model | G-Mini |
| Number of Pump Elements | Up to 2 |
| Number of Sensor Inputs | 1 |
| Power Connection Type | CPC |
| Reservoir Size (L) | 1 |
| Type | Electric Piston Pump |
| Voltage (V dc) | 24 |
| Voltage (V) | 24 |
