Magnum ProX19
Magnum ProX19 Electric TrueAirless Sprayer, Cart
Part Number: 17G180
Magnum ProX19
Magnum ProX19 Electric TrueAirless Sprayer, Cart
Part Number: 17G180
Property maintenance pros, remodelers and general contractors turn projects around smarter and faster with the ProX19 with built-in cart. Tackle all rental property and large interior projects with the ability to spray thicker materials and eliminate downtime with fast, on-the-job pump swaps.
$839.00
USD MSRP
Questions About this Product?
If you’re not finding the information you need, ask one of our experts.
Ask an Expert
Features
Product Brochure
Property maintenance pros, remodelers and general contractors turn projects around smarter and faster with the ProX19 with built-in cart. Tackle all rental property and large interior projects with the ability to spray thicker materials and eliminate downtime with fast, on-the-job pump swaps.
- ProX Stainless Steel Piston Pump - For greater reliability and long life
- ProXChange Pump System - Eliminates downtime with quick, no-tools pump replacement on-the-job
- DC Motor - Supports longer extension cords and up to 150 feet of airless hose
- PushPrime - Fast and reliable start-up every time
- SG3 Metal Spray Gun - Premium spray gun with hose swivel making it easy to manage longer hose lengths
- TrueAirless Spray Tip with SoftSpray Technology - greater control and less overspray with a wide range of coatings
- Convenient Cart - Move paint and sprayer around job site
- Adjustable Pressure - Easy control of paint flow
- InstaClean Pump Filter - Added pump filtration reduces tip clogs from debris in the paint
- Power Flush Adapter - Connects to garden hose for fast and easy cleanup
Specifications & Documents
Technical Specifications
Convert to Metric| Amperage (A) | 8 |
|---|---|
| Compatible Tip Size (in) | 0.009, 0.011, 0.013, 0.015, 0.017, 0.019 |
| Construction | Aluminum, Brass, Carbide, Fluroelastomer, Leather, Nylon, PVC, Plated Steel, Polypropylene, Stainless Steel, UHMWPE |
| Engine Size (HP) | 0.875 |
| Fluid Outlet Size (in) | 1/4 |
| Fluid Outlet Thread Type | NPSM |
| Frame Configuration | Cart |
| Includes | SG3 Spray Gun, TrueAirless 515 Spray Tip, Spray Tip Guard, 1/4 in x 50 ft DuraFlex Hose, Pump Armor Storage Fluid (8 oz), Quick Start-Up Guide |
| Inlet Paint Strainer | 35 Mesh Stainless Steel Screen |
| Maximum Flow Rate (GPM) | 0.38 |
| Maximum Hose Length (ft) | 150 |
| Maximum Tip Size (in) | 0.019 |
| Maximum Tip Size 1 Gun (in) | 0.019 |
| Maximum Working Pressure (MPa) | 20.7 |
| Maximum Working Pressure (psi) | 3000 |
| Minimum Generator Power (W) | 2500 |
| Model | Magnum |
| Motor Type | DC |
| Number of Guns | 1 |
| Outlet Paint Filter | InstaClean |
| Overall Height (in) | 36.7 |
| Overall Length (in) | 20.2 |
| Overall Width (in) | 17.2 |
| Phase | 1 |
| Power Rating (HP) | 0.875 |
| Power Rating (W) | 653 |
| Power Rating (kW) | 0.65 |
| Power Source | Electric |
| Pressure Control Type | Adjustable |
| Product Series | Pro |
| Pump Mount Type | ProXchange |
| Pump Rod Type | Stainless Steel |
| Pump Sleeve Material | Stainless Steel |
| Pump Type | Piston |
| Recommended Annual Usage (gal) | 500 |
| Series | ProX19 |
| Type | Airless Sprayer |
| Voltage (V) | 120 |
| Weight (lb) | 38 |
| Amperage (A) | 8 |
| Compatible Tip Size (in) | 0.009, 0.011, 0.013, 0.015, 0.017, 0.019 |
| Construction | Aluminum, Brass, Carbide, Fluroelastomer, Leather, Nylon, PVC, Plated Steel, Polypropylene, Stainless Steel, UHMWPE |
| Fluid Outlet Size (in) | 1/4 |
| Fluid Outlet Size (mm) | 6.35 |
| Fluid Outlet Thread Type | NPSM |
| Frame Configuration | Cart |
| Includes | SG3 Spray Gun, TrueAirless 515 Spray Tip, Spray Tip Guard, 1/4 in x 50 ft DuraFlex Hose, Pump Armor Storage Fluid (8 oz), Quick Start-Up Guide |
| Inlet Paint Strainer | 35 Mesh Stainless Steel Screen |
| Maximum Flow Rate (L/min) | 1.4 |
| Maximum Hose Length (m) | 45 |
| Maximum Tip Size (in) | 0.019 |
| Maximum Tip Size 1 Gun (in) | 0.019 |
| Maximum Working Pressure (MPa) | 20.7 |
| Maximum Working Pressure (bar) | 207 |
| Maximum Working Pressure (kPa) | 20700 |
| Maximum Working Pressure (psi) | 3000 |
| Minimum Generator Power (W) | 2500 |
| Model | Magnum |
| Motor Type | DC |
| Number of Guns | 1 |
| Outlet Paint Filter | InstaClean |
| Overall Height (cm) | 93.0 |
| Overall Height (mm) | 930 |
| Overall Length (cm) | 51.3 |
| Overall Length (mm) | 513 |
| Overall Width (cm) | 43.7 |
| Overall Width (mm) | 437 |
| Phase | 1 |
| Power Rating (W) | 653 |
| Power Rating (kW) | 0.65 |
| Power Source | Electric |
| Pressure Control Type | Adjustable |
| Product Series | Pro |
| Pump Mount Type | ProXchange |
| Pump Rod Type | Stainless Steel |
| Pump Sleeve Material | Stainless Steel |
| Pump Type | Piston |
| Series | ProX19 |
| Type | Airless Sprayer |
| Voltage (V) | 120 |
| Weight (kg) | 19 |
Product Manuals
Warranty
Sales Literature
What's Included
| Part No. | Description | Qty | Unit |
|---|---|---|---|
| 243012 | SG3 Metal Spray Gun | 1 | ea |
| TRU515 | TrueAirless 515 Spray Tip | 1 | ea |
| 237859 | Spray Tip Guard | 1 | ea |
| 247340 | DuraFlex Hose 1/4 in x 50 ft | 1 | ea |
| 25M568 | FLUID, PUMP ARMOR, 8OZ | 1 | ea |
Repair Parts
| Part No. | Description |
|---|---|
| 17J173 | Magnum ProX Paint Sprayer Replacement Cord |
| 119276 | Replacement Fuse |
| 287770 | Fan, ProX17, ProX19, Stand/Cart |
| 17J881 | Repair Kit, Pressure Control, ProX17, ProX19, Prox21 Stand/Cart |
| 24Y329 | Repair Kit, Switch, ProX17, ProX19, ProX21 Stand/Cart |
| 235014 | Spray Prime/Drain Valve Kit |
| 17J867 | Repair Kit, Control Board, ProX17, ProX19, ProX21 Stand/Cart |
| 17F756 | Repair Kit, Motor, ProX17, ProX19 Stand/Cart |
| 288716 | Inlet Strainer |
| 195108 | TUBE DRAIN |
| 16H348 | TUBE, SUCTION |
