SD™ 10 Series 120 Volt Cord Reel - Tri-Plug GFCI Industrial Receptacle - 95 ft (29 m), 12 AWG, 15 Amp Cord - Black
Part Number: 24Y883
Image is for illustrative purposes only.
SD 10
SD™ 10 Series 120 Volt Cord Reel - Tri-Plug GFCI Industrial Receptacle - 95 ft (29 m), 12 AWG, 15 Amp Cord - Black
Part Number: 24Y883
Organize your work space for a safer, more productive work environment. Make Graco your single source for your entire reel bank.
Questions About this Product?
If you’re not finding the information you need, ask one of our experts.
Ask an ExpertFeatures
Product Brochure
Organize your work space for a safer, more productive work environment. Make Graco your single source for your entire reel bank.
- Heavy-duty steel construction, SD Series size 10.
- 95 foot (29 m) cord and features a 5 foot lead-in cable.
- Tri-Plug GFCI Industrial Receptacle
Adjustable Arm - Easily change the arm position to fit more applications. Works on walls, ceilings or bench mounts.
Heavy-Duty Pedestal - High-strength steel construction with rolled edges and ribbed stress points that won't flex or twist.
Specifications & Documents
Technical Specifications
Convert to Metric| Cord Length (ft) | 95 |
|---|---|
| Includes | Tri-Plug GFCI Industrial Receptacle |
| Insulation Type | SJOOW |
| Maximum Current (A) | 15 |
| Maximum Operating Temperature (°F) | 122 |
| Model | SD |
| Overall Height (in) | 19.5 |
| Overall Length (in) | 17.5 |
| Overall Width (in) | 4.7 |
| Power Cord Connect Type | NEMA 5-15P |
| Reel Color | Black |
| Series | 10 |
| Sound Power Level (dB(A)) | 87 |
| Sound Pressure Level (dB) | 80 |
| Type | Cord Reel |
| Voltage (V ac) | 120 |
| Weight (lb) | 51.8 |
| Wire Gauge (AWG) | 12 |
| Cord Length (m) | 29 |
| Includes | Tri-Plug GFCI Industrial Receptacle |
| Insulation Type | SJOOW |
| Maximum Current (A) | 15 |
| Maximum Operating Temperature (°C) | 50 |
| Model | SD |
| Overall Height (cm) | 49.53 |
| Overall Height (mm) | 495.3 |
| Overall Length (cm) | 44.5 |
| Overall Length (mm) | 445 |
| Overall Width (cm) | 11.938 |
| Overall Width (mm) | 119.38 |
| Power Cord Connect Type | NEMA 5-15P |
| Reel Color | Black |
| Series | 10 |
| Sound Power Level (dB(A)) | 87 |
| Sound Pressure Level (dB) | 80 |
| Type | Cord Reel |
| Voltage (V ac) | 120 |
| Weight (kg) | 23.5 |
| Wire Gauge (AWG) | 12 |
