RAC IV SwitchTip
RAC IV SwitchTip 211
Part Number: 221211
Rac 4 Tip
RAC IV SwitchTip
RAC IV SwitchTip 211
Part Number: 221211
The Reverse-A-Clean (RAC) 211 RAC IV SwitchTip is designed for narrower surfaces and thinner materials like water-based lacquers, stains, and polyurethanes. The 211 SwitchTip has a 0.011 inch orifice and produces a 4 to 6 inch fan. Reverse the SwitchTip to easily clear clogs.
$39.99
USD MSRP
Questions About this Product?
If you’re not finding the information you need, ask one of our experts.
Ask an ExpertFeatures
Product Brochure
The Reverse-A-Clean (RAC) 211 RAC IV SwitchTip is designed for narrower surfaces and thinner materials like water-based lacquers, stains, and polyurethanes. The 211 SwitchTip has a 0.011 inch orifice and produces a 4 to 6 inch fan. Reverse the SwitchTip to easily clear clogs.
Reverse-A-Clean (RAC) IV SwitchTip
- Select different-sized tips based on the material used
- Reversible — quickly clear tip plugs with a twist
- Easily installs on Gun without tools
Specifications & Documents
Technical Specifications
Convert to Metric| Compatible Material | Stains, Lacquer, Polyurethane |
|---|---|
| For Use With | Project Painter Plus, X5, X7, ProX17 Stand, ProX17 Cart, ProX19 Stand, ProX19 Cart, ProX21 Stand, ProX21 Cart |
| Maximum Fan Width (in) | 6 |
| Maximum Flow Rate (GPM) | 0.12 |
| Maximum Working Pressure (psi) | 4050 |
| Minimum Fan Width (in) | 4 |
| Model | RAC IV |
| Orifice Diameter (in) | 0.011 |
| Series | SwitchTip |
| Type | Spray Tip |
| Compatible Material | Stains, Lacquer, Polyurethane |
| For Use With | Project Painter Plus, X5, X7, ProX17 Stand, ProX17 Cart, ProX19 Stand, ProX19 Cart, ProX21 Stand, ProX21 Cart |
| Maximum Fan Width (cm) | 15.2 |
| Maximum Fan Width (in) | 6 |
| Maximum Fan Width (mm) | 152 |
| Maximum Flow Rate (L/min) | 0.45 |
| Maximum Working Pressure (bar) | 280 |
| Maximum Working Pressure (kPa) | 28000 |
| Maximum Working Pressure (psi) | 4050 |
| Minimum Fan Width (mm) | 102 |
| Model | RAC IV |
| Orifice Diameter (in) | 0.011 |
| Series | SwitchTip |
| Type | Spray Tip |
