Oil Ace
Waste Oil Evacuation System with 90 L (24 gal) Steel Tank, Suction Probes, Sight Glass, Oil Drain Funnel and Adapters
Part Number: 26C064
Image is for illustrative purposes only.
Oil Ace
Waste Oil Evacuation System with 90 L (24 gal) Steel Tank, Suction Probes, Sight Glass, Oil Drain Funnel and Adapters
Part Number: 26C064
For shops requiring flexibility when it comes to removing used fluids, use Graco’s multi-purpose used oil evacuation system.
Features
For shops requiring flexibility when it comes to removing used fluids, use Graco’s multi-purpose used oil evacuation system.
Large Offset Collection Pan - Wide offset collection bowl prevents splashing.
Vacuum Gauge - Ensure peak performance with easy-to-read vacuum gauge.
Easy to Drain- Pressurise using shop air for easy oil evacuation.
Vacuum Probes- Variety of flexible suction attachments and adapters included.
Large 90 Litre (24 Gallon) Capacity Receiver - Perfect for small to large shops without an evacuation system.
Sight Glass - Inspect oil quality via large, clear evacuation chamber and verify amount extracted.
Specifications & Documents
Technical Specifications
Convert to Imperial| Compatible Fluid | Used Oil;ATF |
|---|---|
| Maximum Operating Temperature (°F) | 194 |
| Minimum Operating Temperature (°F) | 30 |
| Model | Oil Ace |
| Overall Height (in) | 59.0 to 70.8 |
| Overall Length (in) | 24 |
| Overall Width (in) | 16 |
| Tank Capacity (gal) | 24 |
| Type | Fluid Reclamation Package |
| Weight (lb) | 73.2 |
| Wetted Parts | Steel, Copper, PVC Plastic, Rubber, Aluminium |
| Compatible Fluid | Used Oil;ATF |
| Maximum Operating Temperature (°C) | 90 |
| Minimum Operating Temperature (°C) | -1 |
| Model | Oil Ace |
| Overall Height (cm) | 150 to 180 |
| Overall Length (cm) | 61 |
| Overall Length (mm) | 609.6 |
| Overall Width (cm) | 40.6 |
| Overall Width (mm) | 406.4000 |
| Tank Capacity (L) | 90 |
| Type | Fluid Reclamation Package |
| Weight (kg) | 33.2 |
| Wetted Parts | Steel, Copper, PVC Plastic, Rubber, Aluminium |
