GLC X

GLC X Controller

Part Number: 26A814

product image
Image is for illustrative purposes only.

GLC X

GLC X Controller

Part Number: 26A814

The powerful, new, easy-to-use Graco GLC X auto lubrication controller captures more information in more ways, so operators, technicians and managers can make faster, smarter decisions that drive better productivity.
Questions about this product?

Evaluating our products and need advice
before you buy?

Contact Us

Features

Product Brochure
The powerful, new, easy-to-use Graco GLC X auto lubrication controller captures more information in more ways, so operators, technicians and managers can make faster, smarter decisions that drive better productivity.
  • Indoor/Outdoor Mountable (IP69K) - Designed to withstand all the elements, including high-pressure washes and inclement weather encountered at the harshest and dirtiest sites.
  • Easy-to-Read LED Screen - Soft amber LED lighting capable of displaying text codes, faults and other data clearly in any ambient light without distracting operators.
  • Real-Time System Reporting - Program and display a wide range of customisable functions – including lubrication intervals, pressure limits, lubricant levels and more.
  • Smart Device and Mobile App - With the Auto Lube™ app, monitor lubrication levels, configure settings, track history and share important diagnostics.
  • Universal Compatibility - One controller for all your lubrication systems simplifies training and inventory.
  • Active Current Protection - 9-30 VDC, 10 Amp continuous power supply protects grease pumps from over current and entire system from misfires, electrical shorts and surges.

Specifications & Documents

Technical Specifications

Convert to Imperial
Application In-Plant Machinery, Off-Road Equipment, On-Road Vehicles
Auxiliary Alarm Max Switching Current (A) 10
Auxiliary Alarm Voltage 9-30 VDC
Auxiliary alarm max. switching voltage (VDC) 9-30
Count rate (counts/sec @ 50% duty cycle) 5
Current Consumption (A) 15
Intrusion Rating IP69K
Low Level Alarm Max Switching Current (A) 10
Low level alarm max. switching voltage (VDC) 30
Lubrication Level Input Input 1: 10V
Machine Count Control Input Input 4
Maximum Operating Temperature (°F) 158
Maximum Program Time (min) 99
Maximum Program Time (sec) 5999
Maximum Storage Temperature (°F) 158
Maximum System Cycle Count 100
Maximum Voltage (V dc) 30
Maximum Voltage (V) 30
Minimum Ambient Temperature (°F) -22
Minimum Monitor Time (hrs) 0
Minimum Monitor Time (min) 1
Minimum Monitor Time (sec) 0
Minimum Operating Temperature (°F) -22
Minimum Program Time (hrs) 0
Minimum Program Time (min) 0
Minimum Program Time (sec) 10
Minimum Storage Temperature (°F) -22
Minimum System Cycle Count 1
Minimum Voltage (V dc) 9
Minimum Voltage (V) 9
Minimum monitor time (strokes) 1
Minimum program time (strokes) 1
Model GLC
Number of Pieces 1
Overall Depth (in) 1.98
Overall Height (in) 6.66
Overall Width (in) 3.62
Power Consumption (W) 450
Power Source Electric
Pump Control Max. Switching Current (A) 10
Pump control max switching voltage (VDC) 30
Pump control voltage (VDC) 9-30
Series X
Type Controller
Weight (lb) 0.7
Application In-Plant Machinery, Off-Road Equipment, On-Road Vehicles
Auxiliary Alarm Max Switching Current (A) 10
Auxiliary Alarm Voltage 9-30 VDC
Auxiliary alarm max. switching voltage (VDC) 9-30
Count rate (counts/sec @ 50% duty cycle) 5
Current Consumption (A) 15
Intrusion Rating IP69K
Low Level Alarm Max Switching Current (A) 10
Low level alarm max. switching voltage (VDC) 30
Lubrication Level Input Input 1: 10V
Machine Count Control Input Input 4
Maximum Operating Temperature (°C) 70
Maximum Program Time (min) 99
Maximum Program Time (sec) 5999
Maximum Storage Temperature (°C) 70
Maximum System Cycle Count 100
Maximum Voltage (V dc) 30
Maximum Voltage (V) 30
Minimum Monitor Time (hrs) 0
Minimum Monitor Time (min) 1
Minimum Monitor Time (sec) 0
Minimum Operating Temperature (°C) -30
Minimum Program Time (hrs) 0
Minimum Program Time (min) 0
Minimum Program Time (sec) 10
Minimum Storage Temperature (°C) -30
Minimum System Cycle Count 1
Minimum Voltage (V dc) 9
Minimum Voltage (V) 9
Minimum monitor time (strokes) 1
Minimum program time (strokes) 1
Model GLC
Number of Pieces 1
Overall Depth (cm) 5
Overall Height (cm) 16.9
Overall Height (mm) 169
Overall Width (cm) 9.2
Overall Width (mm) 92
Power Consumption (W) 450
Power Source Electric
Pump Control Max. Switching Current (A) 10
Pump control max switching voltage (VDC) 30
Pump control voltage (VDC) 9-30
Series X
Type Controller
Weight (kg) 319
