TexSpray GTX 2000EX

TexSpray GTX 2000EX Air-Powered Texture Sprayer with Graco Trigger Gun

Part Number: 257030

Available for purchase in: Australia & New Zealand, India, Japan, Korea, Mainland China, China Hong Kong SAR, China Taiwan, Southeast Asia
product image

TexSpray GTX 2000EX

TexSpray GTX 2000EX Air-Powered Texture Sprayer with Graco Trigger Gun

Part Number: 257030

Available for purchase in: Australia & New Zealand, India, Japan, Korea, Mainland China, China Hong Kong SAR, China Taiwan, Southeast Asia
A highly portable texture system for both smooth materials and those with fine aggregates, the GTX 2000EX is the ideal solution for drywall muds, deck coatings, and exterior aggregate acrylic and elastomeric finishes.

Features

A highly portable texture system for both smooth materials and those with fine aggregates, the GTX 2000EX is the ideal solution for drywall muds, deck coatings, and exterior aggregate acrylic and elastomeric finishes.

High-Performance Solutions for Heavy-Duty Jobs. Powered by your external air compressor, this air-powered texture solution gets the job done fast – whether coating a large interior surface or applying an exterior aggregate finish on a large commercial job.

  • Husky 1040 Double Diaphragm Pump
    • Job site Proven Performance
    • Texture delivery rates to 4.0 gpm from durable, high output 1-inch pump
    • Durable, User Friendly Spraying
  • Air Spray Heavy-Duty Trigger Gun
    • Durable, User-Friendly Spraying
    • Pump heavy mud mixes and larger aggregate with oversised fluid passages
    • Quick nozzle changes with extra-coarse gun head threads
  • Largest 64 Litre (17 Gallon) Capacity Hopper

    • Longer Spray Time
    • Easy clean-up and removal with no-tools
  • Separate Pump/Gun Air Controls
    • Complete Control
    • Produce precise, consistent and repeatable texture finishes
  • Skip-Bond Material/Air Hose
    • Improved Handling & Flexibility
    • Both hoses are permanently bonded together for easy handling
    • Oversized grip with no-tools hose connection
  • On-Board Air Filtration
    • Moisture Build-Up Eliminated
    • Automatically filters air to keep your sprayer running at optimal performance
  • Texture Applications
    • Simulated Acoustic (Popcorn)
    • Orange Peel & Fine Splatter
    • Splatter
    • Knock-down
    • Textured Acrylics & Elastomerics
    • EIFS & Synthetic Stucco Finish Coats

Specifications & Documents

Technical Specifications

Convert to Imperial
Compatible Material Primers, Stains, Acrylics, Enamel, Latex, Interior Paint, Exterior Paint
Features Large Capacity Hopper, On-Board Air Filtration, Separate Pump/Gun Air Controls
Includes Heavy-Duty Air Spray Trigger Gun, 1 in x 7.5 m Bonded Material/Air Hose, 3 mm, 4 mm, 6 mm, 8 mm, 10 mm, 12 mm Nozzles
Maximum Flow Rate (gpm) 4.0
Maximum Hose Length (ft) 100
Maximum Working Pressure (MPa) 0.8
Maximum Working Pressure (psi) 3300
Minimum Generator Power (W) 5000
Model TexSpray GTX
Motor Type Brushless DC
Number of Guns 1
Outlet Paint Filter 60 Mesh Stainless Steel Screen
Overall Length (in) 22
Overall Width (in) 24.0340
Phase 1
Power Rating (HP) 2.2
Power Rating (kW) 1.65
Power Source Air
Series 2000EX
Type Airless Sprayer
Weight (lb) 110
Wetted Material Acetal, Aluminium, Brass, Nitrile Rubber, PVC, Polyethylene, Stainless Steel, UHMWPE, Zinc-Plated Carbon Steel
Compatible Material Primers, Stains, Acrylics, Enamel, Latex, Interior Paint, Exterior Paint
Features Large Capacity Hopper, On-Board Air Filtration, Separate Pump/Gun Air Controls
Includes Heavy-Duty Air Spray Trigger Gun, 1 in x 7.5 m Bonded Material/Air Hose, 3 mm, 4 mm, 6 mm, 8 mm, 10 mm, 12 mm Nozzles
Maximum Flow Rate (l/min) 15.1
Maximum Hose Length (m) 30
Maximum Working Pressure (MPa) 0.8
Maximum Working Pressure (bar) 227
Maximum Working Pressure (kPa) 2270
Maximum Working Pressure (kg/cm²) 22.7
Maximum Working Pressure (psi) 3300
Minimum Generator Power (W) 5000
Model TexSpray GTX
Motor Type Brushless DC
Number of Guns 1
Outlet Paint Filter 60 Mesh Stainless Steel Screen
Overall Length (cm) 66
Overall Length (mm) 558.8
Overall Width (cm) 61
Overall Width (mm) 610.4636
Phase 1
Power Rating (kW) 1.65
Power Source Air
Series 2000EX
Type Airless Sprayer
Weight (kg) 50
Wetted Material Acetal, Aluminium, Brass, Nitrile Rubber, PVC, Polyethylene, Stainless Steel, UHMWPE, Zinc-Plated Carbon Steel

What's Included

Part No. Description Qty Unit
248093 GB GUN, SPRAY, TEXTURE, BLEEDER 1 ea

Repair Parts

Part No. Description
246887 PUMP,1040A-PA01AA1GEGEBNPT
